Περιγραφή
| Κατασκευαστής | ASUS |
|---|---|
| Κατασκευαστής επεξεργαστή | INTEL |
| Socket | s1700 |
| Συμβατή Γενιά Επεξεργαστή | 12th / 13th Generation |
| Chipset | B760 |
| Ενσωματωμένος επεξεργαστής | No |
| Τύπος μητρικής | MicroATX |
| Υποστηριζόμενη μνήμη | DDR4 |
| Μέγιστο μέγεθος μνήμης | 128GB |
| Ενσωματωμένη κάρτα γραφικών | Intel HD Graphics support |
| Υποστήριξη CrossfireX / SLI | No / No |
| Ήχος | 8 Channel High Definition |
| SATA 3Gb/s | Όχι |
| SATA 6Gb/s | 4 |
| RAID | SATA RAID 0/1/5/10 |
| PCI Express (x16, x8) | 2 |
| PCI Express (x4) | Όχι |
| PCI Express (x1) | 2 |
| PCI | Όχι |
| USB 2.0 | 2 |
| Firewire / eSATA | No / No |
| Δίκτυο | Ethernet 100 / 1000 / 2500 |
| Σειριακή θύρα / Παράλληλη θύρα | No / No |
| Επιπρόσθετα | Total supports 3 x M.2 slots and 4 x SATA 6Gb/s ports 1 x USB 3.2 Gen 2×2 port (1 x USB Type-C) 2 x USB 3.2 Gen 2 ports (2 x Type-A) 1 x USB 3.2 Gen 1 port (1 x Type-A) 1 x DisplayPort 1 x VGA port 1 x HDMI port 1 x Realtek 2.5Gb Ethernet port https://www.asus.com/motherboards-components/motherboards/prime/prime-b760-plus-d4/ |
| Εγγύηση (μήνες) | 36 |
